Radial Snap-in Surface Mount Conductive Polymer Hybrid Axial Screw

Radial

Series
Features
Operating temperature
Endurance
Voltage
Capacitance
Datasheet

  • RE

    Standard

    -40°C~85°C

    2,000 hours at 85℃

    6.3~450V

    0.1~15000µF

  • RH

    Standard 105°C

    -55°C~105°C

    2,000 hours at 105°C

    6.3~450V

    0.1~15000µF

  • RX

    Low impedance, long life

    -55°C~105°C

    3,000 ~ 6,000 hours at 105°C

    6.3~100V

    0.47~10000µF

  • RL

    Low impedance

    -55°C~105°C

    2,000 hours at 105°C

    6.3~100V

    1~15000µF

  • RW

    Low impedance, long life

    -55°C~105°C

    5,000 ~ 10,000 hours at 105°C

    6.3~100V

    1~680µF

  • RY

    High voltage, long life

    -40°C~105°C

    5,000 ~ 10,000 hours at 105°C

    160~450V

    1~10000µF

  • LL

    Low leakage current

    -40°C~85°C

    2,000 hours at 85°C

    6.3~50V

    0.1~2200µF

  • RB

    Bi-polar

    -40°C~85°C

    2,000 hours at 85°C

    6.3~100V

    0.1~4700µF

  • R7

    Miniature

    -40°C~85°C

    1,000 hours at 85°C

    6.3~100V

    0.1~220µF

  • RJ

    Miniature, high temperature

    -40°C~105°C

    1,000 hours at 105°C

    6.3~50V

    0.1~220µF

  • R5

    Ultra-miniature

    -40°C~85°C

    1,000 hours at 85°C

    6.3~50V

    0.1~100µF

    • Snap-in

    Series
    Features
    Operating temperature
    Endurance
    Voltage
    Capacitance
    Datasheet

  • LS

    Standard

    -40°C~85°C

    2,000 hours at 85°C

    16~450V

    47~33000µF

  • LC

    Long life

    -40°C~85°C

    3,000 hours at 85°C

    16~450V

    33~82000µF

  • LH

    Standard 105°C

    -40°C~105°C

    2,000 hours at 105°C

    16~450V

    47~33000µF

  • LT

    Long life 105°C

    -40°C~105°C

    3,000 hours at 105°C

    16~450V

    33~68000µF

  • LA

    Low ESR, high CV

    -40°C~85°C

    2,000 hours at 85°C

    50~100V

    4700~22000µF

  • LX

    High temperature, long life

    -40°C~105°C

    5,000 hours at 105°C

    16~450V

    47~47000µF

    • Surface Mount

    Series
    Features
    Operating temperature
    Endurance
    Voltage
    Capacitance
    Datasheet

  • VE

    Standard

    -40°C~85°C

    2,000 hours at 85℃

    4~450V

    1~470µF

  • VH

    Standard high temperature

    -55°C~105°C

    2,000 hours at 105°C

    6.3~450V

    0.1~3300µF

  • VX

    Low ESR

    -55°C~105°C

    2,000 hours at 105°C

    6.3~63V

    1~3300µF

  • VT

    Low ESR, long life

    -55°C~105°C

    2,000 ~ 5,000 hours at 105°C

    6.3~100V

    1~3300µF

  • VD

    Ultra long life

    -40°C~105°C

    10,000 hours at 105°C

    400V

    2.2~10µF

  • VP

    Bi-polar

    -40°C~85°C

    2,000 hours at 85°C

    6.3~50V

    0.1~47µF

    • Conductive Polymer Hybrid

    Series
    Features
    Operating temperature
    Endurance
    Voltage
    Capacitance
    Datasheet

  • HMV

    Standard 105°C

    -55°C~105°C

    10,000 hours at 85°C

    25~80V

    22~330µF

  • HMR

    Standard 125°C

    -55°C~125°C

    4,000 hours at 125°C

    16~100V

    22~1800µF

  • HMG

    High temperature 135°C

    -55°C~135°C

    4,000 hours at 135°C

    25~63V

    33~560µF

  • HMY

    Standard 145°C

    -55°C~145°C

    2,000 hours at 145°C

    25~63V

    22~270µF

  • HMW

    Ultra-high temperature

    -55°C~150°C

    1,000 hours at 150°C

    25~63V

    22~270µF

    • Axial

    Series
    Features
    Operating temperature
    Endurance
    Voltage
    Capacitance
    Datasheet

  • TE

    General purpose

    -40°C~85°C

    2,000 hours at 85℃

    10~450V

    1~4700µF

  • TH

    High temperature

    -40°C~105°C

    2,000 hours at 105°C

    10~100V

    1~4700µF

    • Screw

    Series
    Features
    Operating temperature
    Endurance
    Voltage
    Capacitance
    Datasheet

  • CE

    General purpose

    -40°C~85°C

    2,000 hours at 85℃

    16~450V

    680~680000µF

  • CH

    High temperature

    -40°C~105°C

    2,000 hours at 105°C

    16~400V

    1000~470000µF
